Current Rating:
7.5A
Dimensions:
53.1 x 12.5 x 20.2mm
Mounting Type:
Through Hole
Gender:
Male
Body Orientation:
Right Angle
Minimum Operating Temperature:
-55°C
Length:
53.1mm
Housing Material:
Steel
Width:
12.5mm
Depth:
20.2mm
Contact Plating:
Gold
Pitch:
2.76mm
Mounting Hardware:
Boardlocks, 4-40 UNC Female Screwlocks
Number of Contacts:
25
Maximum Operating Temperature:
+125°C
CAD Drawing:
3D CAD Model
Contact Material:
Copper Alloy
Shell Size, Connector Layout:
3 (DB, B)
Flange Feature:
Mating Side, Female Screwlock (4-40)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub
Contact Finish Thickness:
-
Dielectric Material:
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Number of Positions:
25
REACH Status:
REACH Unaffected
edacadModel:
09663626817 Models
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4322551
Voltage Rating:
-
Wire Gauge:
-
Contact Form:
Machined
Connector Type:
Plug, Male Pins
Contact Finish:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder
standardLeadTime:
15 Weeks
Current Rating (Amps):
7.5A
Backset Spacing:
-
Ingress Protection:
-
Features:
Board Lock, Grounding Indents
Mounting Type:
Through Hole, Right Angle
Color:
-
Series:
-
Shell Material, Finish:
Steel
Packaging:
Bulk
Contact Type:
Signal
Contact Material:
Copper Alloy
ECCN:
EAR99
