Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-40°C
Conductor Material:
Copper
Series:
UNITRONIC FD CP (TP) Plus A
Fire Behaviour:
CSA: FT2 acc. to CSA 22.2 No. 2556, Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2, Halogen free acc. to IEC 60754-1 resp. EN 60754-1, UL Horizontal Flame Test acc. to UL 1581
Screened/Unscreened:
Screened
Conductor Type:
Extra Fine
American Wire Gauge:
24AWG
Voltage:
500 V
Jacket Material:
Thermoplastic Polyurethane
Number of Cores:
5
Cable CSA:
0.25 mm²
Product Type:
Control Cable
Maximum Operating Temperature:
80°C
Standards/Approvals:
CSA C22.2 No. 210, CSA 22.2 No. 2556, DIN 47100, EN 50288-7, EN 50363-6, EN 50396, EN 60332-1-2, EN 60754-1, EN 60811-404, EN IEC 60228, EU- 2011/65/EU (RoHS), EU- 2014/35/EU, IEC 60228, IEC 60332-1-2, IEC 60754-1, ISO 4892-2, UL 1581, UL 758, UL AWM Style 11117 and 21576, VDE 0812
