Hazardous Area Certification:
No
Jacket Colour:
Jet Black, Black
Minimum Operating Temperature:
-40°C
Conductor Material:
Copper
Series:
Olflex Chain 809
Fire Behaviour:
Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2 UL VW-1 acc. to UL 1581 § 1080 UL FT2 acc. to UL 1581 § 1100 CSA FT1 acc. to CSA C22.2 No. 2256 § 9.3
Screened/Unscreened:
Unscreened
Conductor Type:
Stranded
American Wire Gauge:
10AWG
Voltage:
1000 V
Jacket Material:
Polyvinyl Chloride
Number of Cores:
1
Cable CSA:
6 mm²
Product Type:
Control Cable
Maximum Operating Temperature:
90°C
Standards/Approvals:
UL 1581, UL 758 AWM Style 10107, IEC 60332 1 2, IEC 60228, EU Regulation no. 305/2011 (CPR), EU 2014/35/EU, EU 2011/65/EU (RoHS), EN ISO 4892 2 2013, EN 60811, EN 60332 1 2, EN 60228, EN 50620, EN 50618, EN 50525 1, EN 50396, EN 50395, EN 50290 2 22, CSA C22.2 No. 2256, CSA C22.2 No. 210, IEC 60811
