Amphenol RF 142138
Product Information
Body Plating:
Gold
Mating Type:
Push-On
Mounting Type:
Through Hole
Gender:
Female
Body Orientation:
Straight
Cable Type:
Coaxial
Coaxial Connector Type:
SMB Connector
Contact Plating:
Gold
Termination Method:
Solder
Operating Frequency:
4GHz
Impedance:
50Ω
Contact Material:
Brass
Maximum Operating Temperature:
+165°C
Minimum Operating Temperature:
-65°C
Size:
Standard
Shield Termination:
Solder
HTSUS:
8536.69.4010
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Center Contact Material:
Brass
Operating Temperature:
-65°C ~ 165°C
Connector Style:
SMB
Body Finish:
Gold
Dielectric Material:
Polytetrafluoroethylene (PTFE)
Insertion Loss:
0.3dB
standardLeadTime:
6 Weeks
Voltage Rating:
335 V
REACH Status:
REACH Affected
Includes:
-
edacadModel:
142138 Models
Frequency - Max:
4 GHz
Housing Color:
Gold
edacadModelUrl:
/en/models/1011989
Impedance:
50 Ohms
Cable Group:
-
Package:
Bag
Connector Type:
Jack, Male Pin
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Number of Ports:
1
Body Material:
Brass
Fastening Type:
Snap-On
Mating Cycles:
500
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Series:
-
Center Contact Plating:
Gold
Contact Termination:
Solder
Base Product Number:
1421
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search 142138 on website for other similar products.
We accept all major payment methods for all products including ET18629126. Please check your shopping cart at the time of order.
You can order Amphenol RF brand products with 142138 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Coaxial Connector (RF) Assemblies category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Amphenol RF 142138. You can also check on our website or by contacting our customer support team for further order details on Amphenol RF 142138.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET18629126 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Amphenol RF" products on our website by using Enrgtech's Unique Manufacturing Part Number ET18629126.
Yes. We ship 142138 Internationally to many countries around the world.
This is manufactured by Amphenol RF. The manufacturer part number is 142138. The body is gold plated for adorable look and strength. It is a type of push-on mating. The product is available in through hole configuration. In addition, female is the available "Gender" of the product. It has straight body orientation. It is a typical coaxial cable. This coaxial connector is a type of smb connector. The high-quality gold is used as contact plating material. It allows solder termination method. Furthermore, the product has 4ghz operating frequency range. It has an impedance value of 50ω. The product is made from sturdy brass materials. It has a maximum operating temperature of +165°c. Whereas, the minimum operating temperature of the product is -65°c. The product is available in standard size. It has a solder shield termination. It is assigned with possible HTSUS value of 8536.69.4010. The product is rohs3 compliant. The brass material is utilised for designing its center contacts. The product has -65°c ~ 165°c operating temperature range. It comes in smb connector style. The body is galvanized with nice finishing of gold. Moreover, the product is constructed from highly polytetrafluoroethylene (ptfe) dielectric material. Allows 0.3db of insertion loss. It has a long 6 weeks standard lead time. Moreover, the product has a nominal 335 v voltage rating. In addition, it is reach affected. It maximum frequency is 4 ghz. It has an integral gold housing colour. It has an impedance value of 50 ohms. It is shipped in bag package . jack, male pin Connector type offer robust functionality. Its typical moisture sensitivity level is 1 (unlimited). This product features 1 number of ports. The product's body is nicely designed from brass materials. Furthermore, snap-on is the Fastening Type of the product. It provides best efficiency with mating cycles of 500. The center contact is plated with a [Center Contract Plating]. It also incorporates solder contact terminals. Moreover, it corresponds to 1421, a base product number of the product. The product is designated with the ear99 code number.
