Contact Material:
Phosphor Bronze
Number of Contacts:
8
Mating Type:
Axial
Pole Format:
8
IP Rating:
IP67
Series:
M128XM
Coding:
X Coded
Contact Gender:
Male
Current:
0.5A
Plug/Socket:
Plug
Standards/Approvals:
CE2011/65/EU (RoHS DIRECTIVE), IEC60695-11-10, UL94 V-0
Voltage:
48 V
Contact Plating:
Gold Plated
Shell Size:
M12
Housing Material:
Brass, Copper Zinc, Thermoplastic
Orientation:
Axial
Product Type:
Industrial Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-40°C
Connector Size:
M12
Mount Type:
Panel
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
8
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Shielded
Cable Opening:
-
Voltage Rating:
48VAC/DC
Current Rating (Amps):
0.5A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Package:
Bag
Shell Size - Insert:
M12-8
Connector Type:
Plug, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Shell Material:
Brass
Termination:
Solder Cup
standardLeadTime:
2 Weeks
Insert Material:
Thermoplastic
Orientation:
X
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
Nickel
Color:
Silver
Series:
M12
Contact Finish Thickness - Mating:
15.0µin (0.38µm)
Contact Material:
Phosphor Bronze
ECCN:
EAR99
