Current Rating:
15.0A
Mating Type:
Push-Pull
Mounting Type:
Front Mount
IP Rating:
IP68
Series:
JMX
Body Orientation:
Straight
Voltage Rating:
300 V
Pole Format:
2P
Contact Gender:
Female
Termination Method:
Crimp
Housing Material:
Polymer
Plug/Socket:
Socket
Contact Plating:
Gold
Shell Size:
1
Number of Contacts:
2
Maximum Operating Temperature:
+100°C
Minimum Operating Temperature:
-20°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
300V
Mounting Feature:
Bulkhead - Rear Side Nut
Operating Temperature:
-20°C ~ 100°C
Shell Size, MIL:
-
Number of Positions:
2
Backshell Material, Plating:
-
Shielding:
Unshielded
Cable Opening:
-
Shell Material:
Polyetherimide (PEI)
REACH Status:
REACH Unaffected
Current Rating (Amps):
10A
edacadModel:
JMXHH1G02FCUDSU Models
Applications:
Industrial, Instrumentation, Medical
Contact Finish - Mating:
Gold
Primary Material:
Plastic
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/7065979
Package:
Bulk
Shell Size - Insert:
1-2
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Pull
Termination:
Crimp
Insert Material:
Polyetheretherketone (PEEK)
Orientation:
G
Ingress Protection:
IP50/IP68 - Dust Protected, Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount
Shell Finish:
-
Color:
Light Gray
Series:
JMX
Contact Finish Thickness - Mating:
19.7µin (0.50µm)
Contact Material:
Copper Nickel
Base Product Number:
JMXHH1
ECCN:
EAR99
