Number of Contacts:
7
Current Rating:
7.5A
Mating Type:
Bayonet
Mounting Type:
Panel Mount
IP Rating:
IP68, IP69K
Minimum Operating Temperature:
-40°C
Series:
UTS
Body Orientation:
Straight
Voltage Rating:
500 V
Contact Gender:
Male
Termination Method:
Solder
Housing Material:
Thermoplastic
Plug/Socket:
Plug
Connector Size:
M14
Contact Plating:
Gold
Shell Size:
14
Strain Relief:
No
Maximum Operating Temperature:
+105°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
Bulkhead - Front Side Nut
Operating Temperature:
-40°C ~ 105°C
Shell Size, MIL:
-
Number of Positions:
7 (6 + PE)
Backshell Material, Plating:
-
Shielding:
Unshielded
Cable Opening:
-
Shell Material:
Polyamide (PA), Nylon
REACH Status:
REACH Unaffected
Current Rating (Amps):
10A
edacadModel:
UTS7147PSEK9 Models
Applications:
Energy, Instrumentation, Lighting, Telecommunications
Contact Finish - Mating:
Gold
Primary Material:
Plastic
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/4493731
Voltage Rating:
500V
Shell Size - Insert:
14-7
Connector Type:
Receptacle, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Bayonet Lock
Termination:
Solder
standardLeadTime:
10 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
N (Normal)
Ingress Protection:
IP68/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
Board Lock, UV Resistant
Mounting Type:
Panel Mount, Through Hole
Shell Finish:
-
Color:
Black
Series:
Trim Trio® UTS
Packaging:
Bulk
Contact Finish Thickness - Mating:
16.0µin (0.41µm)
Contact Material:
Brass
Base Product Number:
UTS71
ECCN:
EAR99
