HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 125°C
Shell Size, MIL:
-
Number of Positions:
9 (8 + 1 Power)
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Shielded
Cable Opening:
0.118" ~ 0.571" (3.00mm ~ 14.50mm)
Voltage Rating:
48VAC, 74VDC
Current Rating (Amps):
8A, 20A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
-
Package:
Bulk
Shell Size - Insert:
M23-9
Connector Type:
Plug, Male Pins
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Threaded
Shell Material:
Gadolinium-Zinc
Termination:
Solder Cup
standardLeadTime:
9 Weeks
Insert Material:
Polybutylene Terephthalate (PBT)
Orientation:
N (Normal)
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
-
Color:
Silver
Series:
CA
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
Pole Format:
8+1
Current:
20A
Shell Size:
M23
Plug/Socket:
Plug
Contact Plating:
Nickel Gold Alloy
Product Type:
Circular Connector
Maximum Operating Temperature:
125°C
Termination Type:
Solder
IP Rating:
IP67
Contact Gender:
Male
Standards/Approvals:
cUL Recognised, cULus Recognised, UL Recognised
Connector Size:
M23
Mount Type:
Cable
Housing Material:
Copper Zinc Alloy, Die Cast Zinc
Orientation:
Angled
Series:
CA
Coding:
N
Voltage:
48 V
Minimum Operating Temperature:
-40°C
Number of Contacts:
9
Contact Material:
Copper Zinc Alloy
