Current Rating:
4.0A
Mating Type:
A Coded
Pole Format:
4P
IP Rating:
IP65, IP67
Series:
SACC
Body Orientation:
Right Angle
Voltage Rating:
250 V
Coding:
A
Contact Gender:
Male
Termination Method:
Push In, Screw
Housing Material:
Polymer
Plug/Socket:
Socket
Connector Size:
M12
Contact Plating:
Nickel over Gold
Shell Size:
15
Mounting Type:
Cable Mount
Number of Contacts:
4
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-40°C
Contact Material:
Copper
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
250VAC/DC
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
4
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Polyamide (PA66), Nylon 6/6
Shielding:
Unshielded
Cable Opening:
0.157" ~ 0.315" (4.00mm ~ 8.00mm)
Shell Material:
Zinc Die Cast
REACH Status:
REACH Unaffected
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Shell Size - Insert:
M12-4
Connector Type:
Plug, Male Pins
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Push-Twist
Termination:
Spring-Cage
standardLeadTime:
8 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6
Orientation:
A
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Features:
Backshell
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
Nickel
Color:
Black, Silver
Series:
SACC
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Tin
Base Product Number:
-
ECCN:
EAR99
