Mount Type:
Cable
Pole Format:
8
Current:
0.5A
Shell Size:
M12
Plug/Socket:
Socket
Contact Plating:
Nickel Gold Alloy
Product Type:
Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-40°C
IP Rating:
IP65, IP67
Contact Gender:
Female
Standards/Approvals:
based on IEC 61076-2-109, cUL Listed, cULus Listed, EAC, EN 50155:2001, UL Listed
Connector Size:
M12
Orientation:
Straight
Housing Material:
Die Cast Zinc
Mating Type:
Standard
Series:
SACC
Coding:
X
Voltage:
48 V ac, 60 V dc
Termination Type:
IDC
Number of Contacts:
8
Contact Material:
Copper Tin
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
8 (Data)
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Zinc Die Cast, Nickel
Shielding:
Shielded
Cable Opening:
0.197" ~ 0.311" (5.00mm ~ 7.90mm)
Shell Material:
Zinc Die Cast
Current Rating (Amps):
0.5A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Voltage Rating:
48VAC, 60VDC
Shell Size - Insert:
M12-8
Connector Type:
Plug, Female Sockets
Moisture Sensitivity Level (MSL):
Not Applicable
Fastening Type:
Threaded
Termination:
IDC
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6
Orientation:
X
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
Nickel
Color:
Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Bronze
ECCN:
EAR99
