Number of Contacts:
5
Orientation:
Vertical
IP Rating:
IP67
Connector Size:
M12
Series:
SACC
Coding:
B
Contact Gender:
Female
Current:
4A
Plug/Socket:
Socket
Standards/Approvals:
CHINA RoHS, cUL, EF3.0, EU REACH SVHC, EU RoHS, UL, UL 94 HB
Voltage:
60 V
Contact Material:
Copper Zinc Alloy
Product Type:
Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-25°C
Mount Type:
Front
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
Flange
Operating Temperature:
-25°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
5
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
-
Cable Opening:
-
Voltage Rating:
60V
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Shell Size - Insert:
M12-5
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Shell Material:
Zinc Die Cast
Termination:
Solder
standardLeadTime:
12 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6
Orientation:
B
Ingress Protection:
IP20
Features:
Board Guide
Mounting Type:
Panel Mount, Through Hole
Shell Finish:
Nickel
Color:
Silver
Series:
SACC
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
