Series:
SACC-CIP-M12FS-8P SMD SH T
Insert Type:
Pin
IP Rating:
IP67
Number of Contacts:
8
Gender:
Female
Material:
Polyamide
Standards/Approvals:
CHINA RoHS, EU RoHS, IEC 61076-2-101, cULus Recognised, EU REACH SVHC
Minimum Operating Temperature:
-40°C
Shell Size:
M12
For Use With:
For Circular Connector Inserts
Product Type:
Circular Connector Insert
Maximum Operating Temperature:
105°C
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-25°C ~ 105°C
Shell Size, MIL:
-
Number of Positions:
8
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
Shielded
Cable Opening:
-
title:
1411953
Shell Material:
-
Current Rating (Amps):
2A
Applications:
-
Primary Material:
-
Material Flammability Rating:
UL94 V-0
Voltage Rating:
30V
Shell Size - Insert:
M12-8
Connector Type:
Insert, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
-
Termination:
Solder
standardLeadTime:
12 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Board Guide, Insert Only, Requires Shell
Mounting Type:
Surface Mount
Shell Finish:
-
Color:
-
Series:
SACC
Packaging:
Tray
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
