HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Voltage Rating:
250V
Mounting Feature:
-
Operating Temperature:
-55°C ~ 105°C
Shell Size, MIL:
-
Number of Positions:
4
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
-
Cable Opening:
-
Shell Material:
-
REACH Status:
REACH Affected
Current Rating (Amps):
4A
Applications:
-
Primary Material:
-
Material Flammability Rating:
UL94 V-0
Package:
Tray
Shell Size - Insert:
M12-4
Connector Type:
Insert, Male Pins
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
-
Termination:
Solder
standardLeadTime:
8 Weeks
Insert Material:
Polyamide (PA), Nylon
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Board Guide, Insert Only, Requires Shell
Mounting Type:
Surface Mount
Shell Finish:
-
Color:
-
Series:
SACC
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
Series:
SACC-CI-M12MS-4P SMD T
Insert Type:
Socket
IP Rating:
IP67
Number of Contacts:
4
Gender:
Male
Material:
Polyamide
Standards/Approvals:
EU RoHS, cULus Recognised, EU REACH SVHC, IEC 61076-2-101, CHINA RoHS
Minimum Operating Temperature:
-55°C
Shell Size:
M12
For Use With:
Circular Connector Inserts
Product Type:
Circular Connector Insert
Maximum Operating Temperature:
105°C
