Number of Contacts:
3
Contact Plating:
Gold
IP Rating:
IP67
Connector Size:
M8
Coding:
A Coded
Contact Gender:
Female
Current:
4A
Plug/Socket:
Socket
Standards/Approvals:
IEC 61076-2-104
Voltage:
60 V
Contact Material:
Copper Tin
Termination Type:
Solder
Product Type:
Circular Connector
Maximum Operating Temperature:
85°C
Minimum Operating Temperature:
-40°C
Mount Type:
Rear
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
Bulkhead - Front Side Nut
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
3
Contact Finish - Mating:
Gold
Backshell Material, Plating:
-
Shielding:
-
Cable Opening:
-
title:
1694363
Shell Material:
Brass
REACH Status:
REACH Affected
Current Rating (Amps):
4A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 HB
Voltage Rating:
50VAC, 60VDC
Shell Size - Insert:
M8-3
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Termination:
Solder
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
-
Mounting Type:
Panel Mount, Through Hole
Shell Finish:
Nickel
Color:
Silver
Series:
DSI
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Tin
ECCN:
EAR99
