Contact Material:
Copper Tin
Number of Contacts:
2
IP Rating:
IP65, IP67
Connector Size:
M12
Series:
SACC
Coding:
B
Contact Gender:
Female
Current:
4A
Plug/Socket:
Socket
Standards/Approvals:
cUL, cULus, IEC 61076-2-101, RoHS, UL
Voltage:
60 V
Minimum Operating Temperature:
-40°C
Shell Size:
M12
Product Type:
Circular Connector
Maximum Operating Temperature:
85°C
Mount Type:
Cable
HTSUS:
8536.69.4020
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Operating Temperature:
-40°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
2
Backshell Material, Plating:
Zinc Die Cast, Nickel
Shielding:
Shielded
Cable Opening:
0.197" ~ 0.382" (5.00mm ~ 9.70mm)
title:
1413932
Shell Material:
Zinc Die Cast
REACH Status:
REACH Unaffected
Current Rating (Amps):
4A
edacadModel:
1413932 Models
Applications:
-
Contact Finish - Mating:
Gold
Primary Material:
Metal
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/5695290
Voltage Rating:
48VAC, 60VDC
Shell Size - Insert:
M12-2
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Push-Twist
Termination:
IDC
standardLeadTime:
8 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6, Halogen Free
Orientation:
B
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line)
Shell Finish:
Nickel
Color:
Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Tin
ECCN:
EAR99
