Current Rating:
9.0A
Mating Type:
Screw On
Mounting Type:
Cable Mount
IP Rating:
IP67
Series:
SACC
Body Orientation:
Right Angle
Voltage Rating:
300.0 V
Coding:
A
Contact Gender:
Female
Termination Method:
Screw
Housing Material:
Thermoplastic
Plug/Socket:
Socket
Connector Size:
7/8
Contact Plating:
Gold
Shell Size:
7/8"-16
Number of Contacts:
5
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-25°C
Contact Material:
Brass
HTSUS:
8536.69.4020
RoHS Status:
RoHS Compliant
Mounting Feature:
-
Operating Temperature:
-25°C ~ 85°C
Shell Size, MIL:
-
Number of Positions:
5
Contact Finish - Mating:
Gold
Backshell Material, Plating:
Polybutylene Terephthalate (PBT)
Shielding:
-
Cable Opening:
0.394" ~ 0.472" (10.00mm ~ 12.00mm)
Shell Material:
Zinc Die Cast
Current Rating (Amps):
9A
Applications:
-
Primary Material:
Metal
Material Flammability Rating:
UL94 HB
Voltage Rating:
300V
Shell Size - Insert:
7/8"-5
Connector Type:
Receptacle, Female Sockets
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Fastening Type:
Threaded
Termination:
Screw
standardLeadTime:
4 Weeks
Insert Material:
Polyamide (PA66), Nylon 6/6 and Polyurethane (PUR)
Orientation:
A
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Backshell, Coupling Nut
Mounting Type:
Free Hanging (In-Line), Right Angle
Shell Finish:
Nickel
Color:
Black, Silver
Series:
SACC
Packaging:
Bulk
Contact Finish Thickness - Mating:
-
Contact Material:
Copper Zinc
ECCN:
EAR99
