Category:
Power MOSFET
Dimensions:
10.31 x 9.45 x 4.57mm
Maximum Continuous Drain Current:
7.3 A
Transistor Material:
Si
Width:
9.45mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
650 V
Maximum Gate Threshold Voltage:
3.5V
Maximum Drain Source Resistance:
600 mΩ
Package Type:
D2PAK (TO-263)
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
2.5V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
20.5 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
440 pF @ 100 V
Length:
10.31mm
Pin Count:
3
Typical Turn-Off Delay Time:
80 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
63 W
Series:
CoolMOS C6
Maximum Gate Source Voltage:
-30 V, +30 V
Height:
4.57mm
Typical Turn-On Delay Time:
12 ns
Minimum Operating Temperature:
-55 °C
