Category:
Power MOSFET
Dimensions:
6.73 x 6.22 x 2.41mm
Maximum Continuous Drain Current:
90 A
Transistor Material:
Si
Width:
6.22mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
100 V
Maximum Gate Threshold Voltage:
3.5V
Package Type:
TO-252
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
2V
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
51 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
3690 pF @ 50 V
Length:
6.73mm
Pin Count:
3
Typical Turn-Off Delay Time:
37 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
150 W
Series:
OptiMOS 3
Maximum Gate Source Voltage:
±20 V
Height:
2.41mm
Typical Turn-On Delay Time:
19 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
12.3 mΩ
