Maximum Temperature:
+70°C
AC or DC Output Voltage:
Dc
Dimensions:
125.2 x 63 x 113.5mm
Minimum Temperature:
-25°C
AC or DC Input Voltage:
Ac
Width:
63mm
MTBF:
169.3kh
Maximum Output Voltage:
55V dc
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Mounting Type:
DIN Rail
Type:
Switch Mode
Holdup Time:
20 ms @ 115 V ac, 20 ms @ 230 V ac
Load Regulation:
±1%
Standards Met:
EN 60204-1, EN 61000-6-2, RoHS Compliant, TUV EN 60950-1, UL 508
Maximum Input Current:
1.3 A @ 230 V ac, 2.6 A @ 115 V ac
Input Frequency Range:
47 → 63Hz
Efficiency:
94%
Input Voltage:
88 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
48 → 55V
Line Regulation:
±0.5%
Ripple And Noise:
120mV Pk-Pk
Depth:
113.5mm
Minimum Output Voltage:
48V dc
Special Features:
Built-In Active PFC Function, Built-In DC OK Relay Contact, Cooling by Free Air Convection, Installed on DIN Rail TS-35/7.5 or 15, Low-Power Dissipation, 3-Years Warranty, 100% Full Load Burn-In Test, 150% Peak Load Capacity
Power Signal Conversion Type:
AC-DC
Weight:
1.03kg
Output Current:
5 A
Application:
Electromechanical, Factory Automation, Marine Related Installation, Semiconductor Fabrication Equipment
Output Voltage:
48 V dc
Power Rating:
240W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
88V ac
