Category:
Power MOSFET
Dimensions:
5 x 4 x 1.65mm
Maximum Continuous Drain Current:
14.9 A
Transistor Material:
Si
Width:
4mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
30 V
Maximum Gate Threshold Voltage:
2.2V
Package Type:
DSO
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
102 nC @ 10 V
Channel Type:
P
Typical Input Capacitance @ Vds:
4430 pF @ -25
Length:
5mm
Pin Count:
8
Typical Turn-Off Delay Time:
130 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
2.5 W
Series:
OptiMOS P
Maximum Gate Source Voltage:
±25 V
Height:
1.65mm
Typical Turn-On Delay Time:
15 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
8 mΩ
