Maximum Temperature:
+40°C
Minimum Temperature:
0°C
Regulator Type:
Switched Mode Power Supply
MTBF:
>30000h
Protection Features:
Over Current Protection, Over Temperature Protection, Over Voltage Protection, Short Circuit Protection
Output Current Range:
1.87A
Maximum Input Current:
≤2A
Holdup Time:
≥8.3ms
Standards Met:
CB, CE, CEC, CTUVus, EUP II, FCC, RoHS Compliant, TUV
Input Connector:
IEC320-C8
Input Frequency Range:
50 → 60Hz
Efficiency:
86.16%
Energy Efficiency Level:
V
Overall Length:
88mm
Overall Depth:
50mm
Number of Outputs:
1
Operating Temperature Range:
0 → +40 °C
Rated Output Power:
45W
Ripple And Noise:
300mV
Output Voltage Rating:
24 V dc
Special Features:
Fanless Operation, Power On LED Indicator, Wide Input Range
Power Signal Conversion Type:
AC-DC
Overall Dimensions:
88 x 16.8 x 50mm
Weight:
290g
Mounting Type:
Desktop
Line Regulation Range:
±1%
Overall Width:
16.8mm
Plug Type:
C8
Output Connection Type:
1.75 x 4.75 x 11 mm Centre Positive Female Coaxial Plug, 2.1 x 5.5 x 10.5 mm Centre Positive Female Coaxial Plug, 2.5 x 5.5 x 12.5 mm Centre Positive Female Coaxial Plug, 3 x 6.3 x 12 mm Centre Positive Female Coaxial Plug
Load Regulation Range:
±5%
Input Voltage Range:
100 → 240 V ac
