Maximum Temperature:
+60°C
AC or DC Output Voltage:
Dc
Dimensions:
93 x 100 x 56mm
Minimum Temperature:
-20°C
AC or DC Input Voltage:
Ac
Width:
100mm
MTBF:
486kh
Maximum Output Voltage:
29V dc
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Mounting Type:
DIN Rail
Type:
Switch Mode
Holdup Time:
18 ms @ 115 V ac, 50 ms @ 230 V ac
Load Regulation:
±1%
Standards Met:
EN 50178, RoHS Compliant, TUV EN 60950-1, UL 508
Maximum Input Current:
1.6 A @ 230 V ac, 3 A @ 115 V ac
Input Frequency Range:
47 → 63Hz
Efficiency:
89%
Input Voltage:
88 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
24 → 29V
Line Regulation:
±1%
Ripple And Noise:
150mV Pk-Pk
Depth:
56mm
Minimum Output Voltage:
24V dc
Special Features:
Cooling by Free Air Convection, Installed on DIN Rail TS-35/7.5 or 15, Isolation Class II, LED Indicator For Power On, Universal AC Input/Full Range, 3-Years Warranty, 100% Full Load Burn-In Test
Power Signal Conversion Type:
AC-DC
Weight:
0.35kg
Output Current:
4.2 A
Application:
Commercial & Residential Household Appliances & Building Automation Controls
Output Voltage:
24 V dc
Power Rating:
100.8W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
88V ac
