Dimensions:
6.73 x 6.22 x 2.39mm
Maximum Continuous Drain Current:
35 A
Transistor Material:
Si
Width:
6.22mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
30 V
Maximum Gate Threshold Voltage:
2.2V
Maximum Drain Source Resistance:
15.5 mΩ
Package Type:
TO-251
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
1V
Maximum Operating Temperature:
+175 °C
Typical Gate Charge @ Vgs:
6.6 nC @ 4.5 V
Channel Type:
N
Typical Input Capacitance @ Vds:
1100 pF @ 15 V
Length:
6.73mm
Pin Count:
3
Typical Turn-Off Delay Time:
14 ns
Mounting Type:
Through Hole
Channel Mode:
Enhancement
Maximum Power Dissipation:
38 W
Series:
OptiMOS 3
Maximum Gate Source Voltage:
±20 V
Height:
2.39mm
Typical Turn-On Delay Time:
3.7 ns
Minimum Operating Temperature:
-55 °C
