This is SPST PCB Mount Non-Latching Relay 24V dc Coil manufactured by TE Connectivity. The manufacturer part number is 7-1393215-9. The given dimensions of the product include 28 x 10.4 x 25.1mm. The coil voltage of the product is 24 v dc. Applications Information involves power. It holds up to 1.2 kω coil resistance. It is capable of doing 20000 (electrical) cycles, 20000000 (mechanical) cycles in a lifetime . Robust coil power of 480mw. The product has 4kv rms isolation coil to contact. It has a maximum operating temperature of +70°c. The terminal is a through hole type. It has a maximum 5 a switching current AC . The product has -40 → +70°c of operating temperature range. The contact is equipped with spst configuration. The product comes in 10.4mm depth. The product also provides special features, such as wash tight. The product is available in pcb mount configuration. Its accurate length is 28mm. In addition, the height is 25.1mm. It has a maximum AC switching voltage of 400v ac. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 1.25 kva. The product is made from sturdy silver alloy materials. Its typical moisture sensitivity level is vendor undefined. It is assigned with possible HTSUS value of 8536.41.0050. It is shipped in box package . The product is rohs non-compliant. In addition, it is reach info available upon request. The product is designated with the ear99 code number.
For more information please check the datasheets.
