Dimensions:
6.5 x 5.5 x 2.3mm
Maximum Continuous Drain Current:
5 A
Transistor Material:
Si
Width:
5.5mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
60 V
Maximum Gate Threshold Voltage:
3V
Package Type:
SC-63
Number of Elements per Chip:
1
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
8 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
290 pF @ 25 V
Length:
6.5mm
Pin Count:
3
Typical Turn-Off Delay Time:
26 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
15 W
Maximum Gate Source Voltage:
-20 V, +20 V
Height:
2.3mm
Typical Turn-On Delay Time:
8 ns
Maximum Drain Source Resistance:
140 mΩ
