Maximum Temperature:
+60°C
AC or DC Output Voltage:
Dc
Dimensions:
78 x 56 x 93mm
Minimum Temperature:
-20°C
AC or DC Input Voltage:
Ac
Protection Features:
Over Voltage Protection, Overload Protection, Short Circuit Protection
Width:
56mm
MTBF:
216200h
Maximum Output Voltage:
13.2V dc
Electrical Phase:
1
Mounting Type:
DIN Rail
Type:
Switch Mode
Holdup Time:
23 ms @ 115 V ac, 100 ms @ 230 V ac
Load Regulation:
±1%
Standards Met:
EN 50178, RoHS Compliant, TUV EN 60950-1, UL 508
Maximum Input Current:
0.8 A @ 230 V ac, 1.2 A @ 115 V ac
Input Frequency Range:
47 → 63Hz
Efficiency:
82%
Input Voltage:
88 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
11.1 → 13.2V
Line Regulation:
±1%
Ripple And Noise:
120mV Pk-Pk
Depth:
93mm
Minimum Output Voltage:
11.1V dc
Special Features:
Cooling by Free Air Convection, Installed on DIN Rail TS-35/7.5 or 15, Isolation Class II, LED Indicator For Power On, Universal AC Input/Full Range, 3-Years Warranty, 100% Full Load Burn-In Test
Input Electrical Phase:
Single Phase
Power Signal Conversion Type:
AC-DC
Weight:
0.3kg
Output Current:
4.5 A
Application:
Commercial & Residential Household Appliances & Building Automation Controls
Output Voltage:
12 V dc
Power Rating:
54W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
88V ac
