Maximum Temperature:
+70°C
AC or DC Output Voltage:
Dc
Dimensions:
100 x 40 x 90mm
Minimum Temperature:
-20°C
AC or DC Input Voltage:
Ac
Protection Features:
Over Voltage Protection, Overload Protection, Short Circuit Protection
Width:
40mm
MTBF:
299200h
Maximum Output Voltage:
15V dc
Electrical Phase:
1
Mounting Type:
DIN Rail
Type:
Switch Mode
Holdup Time:
20 ms @ 115 V ac, 50 ms @ 230 V ac
Load Regulation:
±1%
Standards Met:
RoHS Compliant, TUV EN 60950-1, UL 508, UL 60950-1
Maximum Input Current:
1 A @ 230 V ac, 1.8 A @ 115 V ac
Input Frequency Range:
47 → 63Hz
Efficiency:
86%
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
12 → 15V
Line Regulation:
±1%
Ripple And Noise:
120mV Pk-Pk
Depth:
90mm
Minimum Output Voltage:
12V dc
Special Features:
Built-In DC OK Active Signal, Cooling by Free Air Convection, Installed on DIN Rail TS-35/7.5 or 15, LED Indicator For Power On, Universal AC Input/Full Range, 3-Years Warranty, 100% Full Load Burn-In Test
Input Electrical Phase:
Single Phase
Power Signal Conversion Type:
AC-DC
Weight:
0.33kg
Output Current:
5 A
Output Voltage:
12 V dc
Power Rating:
60W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
85V ac
