Direction Type:
Bi-Directional, Uni-Directional
Maximum Peak Pulse Current Ippm:
252A
Width:
8.15 mm
Peak Pulse Power Dissipation Pppm:
5000W
Diode Configuration:
Single Bi-Directional
Automotive Standard:
No
Maximum Reverse Leakage Current:
0.2μA
Clamping Voltage VC:
14V
Package Type:
DO-214AB (SMC)
Number of Elements per Chip:
1
Product Type:
TVS Diode
Maximum Operating Temperature:
175°C
ESD Protection:
Yes
Minimum Breakdown Voltage Vbr:
12V
Length:
6.25mm
Standards/Approvals:
IEC 61000-4-2, JESD-201 Class 2, MIL STD 883 Method 3015, IEC 61000-4-4, MIL-STD-750 Method 2026, UL94 V0, JESD 22-B102 E3, J-STD-002, ECOPACK, J-STD-020
Pin Count:
2
Mount Type:
Surface
Series:
SMC50J
Height:
2.45mm
Minimum Operating Temperature:
-55°C
Test Current It:
10mA
Voltage - Clamping (Max) @ Ipp:
19.9V
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 175°C (TJ)
Package / Case:
DO-214AB, SMC
Type:
Zener
Voltage - Breakdown (Min):
13.3V
Applications:
General Purpose
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Bidirectional Channels:
1
standardLeadTime:
21 Weeks
Current - Peak Pulse (10/1000µs):
252A
Voltage - Reverse Standoff (Typ):
12V (Max)
Mounting Type:
Surface Mount
Series:
SMC50J
Supplier Device Package:
SMC
Packaging:
Tape & Reel (TR)
Capacitance @ Frequency:
-
Power Line Protection:
No
Power - Peak Pulse:
5000W (5kW)
