Texas Instruments TPD8S009DSMR
Product Information
Maximum Peak Pulse Current:
2.5A
Maximum Reverse Stand-off Voltage:
5.5V
Dimensions:
6.6 x 2.6 x 0.75mm
Mounting Type:
Surface Mount
Direction Type:
Uni-Directional
Maximum Operating Temperature:
+85 °C
ESD Protection:
Yes
Peak Pulse Power Dissipation:
25W
Height:
0.75mm
Width:
2.6mm
Length:
6.6mm
Package Type:
SON
Number of Elements per Chip:
8
Minimum Operating Temperature:
-40 °C
Minimum Breakdown Voltage:
9V
Diode Configuration:
Complex Array
Pin Count:
15
Test Current:
1mA
Voltage - Clamping (Max) @ Ipp:
-
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 85°C (TA)
Package / Case:
15-SMD, No Lead
Type:
Steering (Rail to Rail)
edacadModel:
TPD8S009DSMR Models
REACH Status:
REACH Unaffected
Voltage - Breakdown (Min):
9V
Applications:
HDMI
edacadModelUrl:
/en/models/1907466
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Unidirectional Channels:
8
standardLeadTime:
6 Weeks
Current - Peak Pulse (10/1000µs):
-
Voltage - Reverse Standoff (Typ):
5.5V (Max)
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
15-SON
Capacitance @ Frequency:
-
Power Line Protection:
No
Power - Peak Pulse:
25W
Base Product Number:
TPD8S009
ECCN:
EAR99
