Minimum Operating Temperature:
-40°C
Maximum Voltage:
100, 250, 75V dc
Series:
VAL
Length:
35.6mm
Height:
97mm
Hazardous Area Certification:
No
Depth:
77.5mm
Standards/Approvals:
EN 61643-11, IEC 61643-11
Maximum Surge Current:
30kA
Product Type:
Surge Arrester
Maximum Operating Temperature:
80°C
Suppressor Type:
Lightning Arrester
Mount Type:
DIN Rail
HTSUS:
8536.30.8000
RoHS Status:
RoHS Compliant
Voltage - Continuous Operating (Max) (MCOV):
100VDC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
CB, CCA, cUL, cULus, EAC, KEMA-KEUR, UL, VDE
Type:
Type 1, Type 2
Form:
Module Only
Voltage - Protection Level (VP) (2416):
800 V
Current - Discharge (Nom) (8/20µS):
12.5 kA
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
10 Weeks
Current - Short Circuit Rating (SCCR):
25 kA
Features:
Remote Signaling Contacts
Mounting Type:
DIN Rail
Series:
-
Packaging:
Bulk
ECCN:
EAR99
Number of Poles:
2
Current - Discharge (Max) (8/20µS):
30 kA
