Wurth WE-PD3 Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 μH ±20% 1.8A Idc

74451022 Wurth WE-PD3 Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 μH ±20% 1.8A Idc
74451022 Wurth WE-PD3 Series Shielded Wire-wound SMD Inductor with a Ferrite Core, 2.2 μH ±20% 1.8A Idc
Wurth Elektronik

Product Information

Automotive Standard:
No
Maximum DC Resistance:
50mΩ
Product Type:
Wirewound Surface Mount Inductor
Shielding:
Yes
Minimum Operating Temperature:
-40°C
Maximum DC Current:
1.8A
Series:
WE-PD3
Termination Style:
Surface Mount
Length:
6.6mm
Pin Count:
2
Depth:
4.45mm
Standards/Approvals:
JEDEC JS709B, REACH, RoHS
Core Material:
Ferrite
Inductance:
2.2 μH
Maximum Self Resonant Frequency:
120MHz
Inductor Construction:
Shielded
Height:
2.92mm
Maximum Operating Temperature:
125°C
Moulded:
Yes
Inductance Tolerance:
±20 %
Checking for live stock

This is Wurth WE-PD3 Series Shielded Wire-wound SMD Inductor with a Ferrite Core 2.2 μH ±20% 1.8A Idc manufactured by Wurth Elektronik. The manufacturer part number is 74451022. The product complies with automotive standard - no. It allows up to 50mω maximum DC resistance. wirewound surface mount inductor is a versatile product designed to provide user-defined applications. Furthermore, the product is shielded with yes. Whereas, the minimum operating temperature of the product is -40°c. While it carries 1.8a of maximum DC current. The product we-pd3, is a highly preferred choice for users. Moreover, it has surface mount terminal style. Its accurate length is 6.6mm. It contains 2 pins. The product comes in 4.45mm depth. The core is manufactured from highly durable and reliable ferrite materials. The product has a 2.2 μh inductance value. It provides 120mhz of maximum self-resonant frequency. The inductor is designed as shielded inductor. In addition, the height is 2.92mm. It has a maximum operating temperature of 125°c. In addition, it is moulded yes . It has a standard ±20 % inductance tolerance .

pdf icon
WE eiSos Embedded Flyer(Technical Reference)
pdf icon
Power-choke WE-PD3(Technical Reference)
