2 Output Flyback Gate Drive Transformer, 9 To 18V, 18μH

750317894 2 Output Flyback Gate Drive Transformer, 9 To 18V, 18μH
750317894 2 Output Flyback Gate Drive Transformer, 9 To 18V, 18μH
Wurth Elektronik

Product Information

Number of Outputs:
2
Secondary Current:
0.16 A
Turns Ratio:
2.25:3.5:1
Primary Current:
1.95A
Primary Voltage:
9/18 V
Leakage Inductance:
600nH
Series:
WE-AGDT
Length:
11.3mm
Width:
10.95 mm
Depth:
11.9mm
Number of Pins:
8
Inductance:
18 μH
Standards/Approvals:
RoHS, REACH
Secondary Voltage:
18 V
Product Type:
Gate Drive Transformer
Maximum Operating Temperature:
130°C
Minimum Operating Temperature:
-40°C
Mount Type:
Surface
RoHs Compliant
Checking for live stock

This is 2 Output Flyback Gate Drive Transformer 9 To 18V 18μH manufactured by Wurth Elektronik. The manufacturer part number is 750317894. Additionally, the product is supplied with 2 outputs. It has about 0.16 a secondary current . It has 2.25:3.5:1 turns ratio . It has about 600nh leakage inductance . The product we-agdt, is a highly preferred choice for users. Its accurate length is 11.3mm. Furthermore, the product is 10.95 mm wide. The product comes in 11.9mm depth. It is comprised of 8 pins. The product has a 18 μh inductance value. gate drive transformer is a versatile product designed to provide user-defined applications. It has a maximum operating temperature of 130°c. Whereas, the minimum operating temperature of the product is -40°c. It has a surface type mount .

pdf icon
Datasheet - 750317894(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. We ship 750317894 Internationally to many countries around the world.
Yes. You can also search 750317894 on website for other similar products.
We accept all major payment methods for all products including ET21645475. Please check your shopping cart at the time of order.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET21645475 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search"Wurth Elektronik" products on our website by using Enrgtech's Unique Manufacturing Part Number ET21645475.
You can order Wurth Elektronik brand products with 750317894 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in SMPS Transformers category are shipped in lowest possible time.
You will get a confirmation email regarding your order of 2 Output Flyback Gate Drive Transformer, 9 To 18V, 18μH. You can also check on our website or by contacting our customer support team for further order details on 2 Output Flyback Gate Drive Transformer, 9 To 18V, 18μH.
