Phoenix Contact 1522529
Product Information
American Wire Gauge:
24 AWG
Current Rating:
2 A
Oil Resistant:
Yes
Number of Cores:
8
Outer Diameter:
5.9mm
Shielding:
Unshielded
Standards Met:
cULus
Cable Shape:
Twisted Pair
Voltage Rating:
30 V
Operating Temperature Range:
-25 → +90 °C
Maximum Operating Temperature:
+90°C
IP Rating:
IP65, IP67, IP68
Connector 1 Orientation:
Straight
Minimum Bend Radius:
8 x D (Fixed), 10 x D (Flexible)
Fire Behaviour:
Flame Retardant
Connector 1 Gender:
Male
Length:
10m
Sheath Material:
PUR
Conductor Material:
Bare Cu litz wires
Series:
SAC-8P
Connector 1 Housing Gender:
Male
Connector 1 Number of Contacts:
8
Coding:
A
Sheath Colour:
Black/Grey
Cross Sectional Area:
0.25 mm²
Minimum Operating Temperature:
-25°C
Connector 2:
Unterminated
Connector 1:
M12
Insulation Material:
PP
1st Connector Orientation:
A
2nd Connector Mounting Type:
-
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Cable Material:
Polyurethane (PUR)
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M12
REACH Status:
REACH Unaffected
2nd Connector Type:
Wire Leads
Assembly Configuration:
Standard
2nd Connector Number of Positions:
-
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
32.8' (10.00m)
1st Connector Gender:
Male Pins
standardLeadTime:
8 Weeks
1st Connector Type:
Receptacle
2nd Connector Shell Size - Insert:
-
1st Connector Number of Positions:
8
Ingress Protection:
IP65/IP67/IP68 - Dust Tight, Water Resistant, Waterproof
Color:
Black
Series:
-
2nd Connector Orientation:
-
Cable Type:
Round
2nd Connector Number of Positions Loaded:
-
2nd Connector Gender:
-
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search 1522529 on website for other similar products.
We accept all major payment methods for all products including ET10194720. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 1522529 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Sensor & Actuator Cables category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact 1522529. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact 1522529.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET10194720 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET10194720.
Yes. We ship 1522529 Internationally to many countries around the world.
This is manufactured by Phoenix Contact. The manufacturer part number is 1522529. Features 24 awg - American Wire Gauge. The product has a current rating of 2 a. Additionally, it is oil resistant yes . The product consists of 8 cores. Its outer diameter is 5.9mm. Furthermore, the product is shielded with unshielded. The product complies with all safety standards, such as culus. Moreover, this cable has a twisted pair shape. Moreover, the product has a nominal 30 v voltage rating. The product has -25 → +90 °c of operating temperature range. It has a maximum operating temperature of +90°c. It is IP rated with ip65, ip67, ip68. The connector 1 has a straight orientation. It bears 8 x d (fixed), 10 x d (flexible) of minimum bend radius. The product has a flame retardant fire behaviour. This connector 1 is a male. Its accurate length is 10m. The sheath is constructed from durable and adorable pur material. The conductor is made from bare cu litz wires material. The product sac-8p, is a highly preferred choice for users. On the other hand, the gender of connector 1's housing is male. There are 8 contacts on connector 1. The product is coded with a. The sheath has an adorable black/grey colour. The product has 0.25 mm² cross section area. Whereas, the minimum operating temperature of the product is -25°c. While the Connector 2 is unterminated. Connector 1 is m12. It has a robust pp insulation material. This connector has a a orientation. It is assigned with possible HTSUS value of 8544.42.9090. The product is rohs3 compliant. The cable is constructed from highly durable polyurethane (pur) materials. The product's typical Applications include uses in industrial environments. While the loaded positions on first connector are all. The size of the first connector's shell - insert is m12. In addition, it is reach unaffected. The second connector is the wire leads. The product is designed in a standard assembly configuration. It is shipped in bulk package . Its typical moisture sensitivity level is 1 (unlimited). Its accurate length is 32.8' (10.00m). The first connectors are male pins. It has a long 8 weeks standard lead time. receptacle is the first connector. The first connector contains 8 positions. It is IP rated with ip65/ip67/ip68 - dust tight, water resistant, waterproof. It has a classic black colour. It is a typical round cable. The first connector is configured with a free hanging (in-line) mounting type. The product is designated with the ear99 code number.
