Frequency Range:
824MHz ~ 960MHz, 1.575GHz ~ 1.602GHz 1.71GHz ~ 2.17GHz, 2.4GHz ~ 2.5GHz, 4.7GHz ~ 5.9GHz
HTSUS:
8529.10.9100
RoHS Status:
ROHS3 Compliant
Frequency Group:
Wide Band
Height (Max):
1.555" (39.50mm)
REACH Status:
REACH Unaffected
Applications:
CDMA, GLONASS, GPS, GSM, HSPA, UMTS, Wi-Fi
Gain:
2.1dBi, -0.2dBi, 2.9dBi, 3dBi, 5.1dBi, 2.1dBi, 2.9dBi, 3.8dBi, 2.8dBi
Number of Bands:
11
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
RF Family/Standard:
Cellular, Navigation, WiFi
Frequency (Center/Band):
850MHz, 900MHz, 1.575GHz, 1.602GHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 4.85GHz, 5.2GHz, 5.65GHz
Termination:
SMA Male (3)
standardLeadTime:
11 Weeks
Ingress Protection:
IP67
Features:
Cable - 3m, LNA, Filter
Mounting Type:
Panel Mount
Antenna Type:
Dome
Series:
Spartan
VSWR:
2, 1.6
Return Loss:
-
Base Product Number:
MA600
ECCN:
7A994
This is manufactured by Taoglas Limited. The manufacturer part number is MA600.A.ABC.006. The frequency range includes 824mhz ~ 960mhz, 1.575ghz ~ 1.602ghz 1.71ghz ~ 2.17ghz, 2.4ghz ~ 2.5ghz, 4.7ghz ~ 5.9ghz. It is assigned with possible HTSUS value of 8529.10.9100. The product is rohs3 compliant. The product boasts a wide band frequency group. Additionally, the 1.555" (39.50mm) is the maximum height of the product. In addition, it is reach unaffected. The product is widely employed in cdma, glonass, gps, gsm, hspa, umts, wi-fi. The 2.1dbi, -0.2dbi, 2.9dbi, 3dbi, 5.1dbi, 2.1dbi, 2.9dbi, 3.8dbi, 2.8dbi is the gain value of a bespoke product. It contains 11 bands. It is shipped in box package . Its typical moisture sensitivity level is 1 (unlimited). The standard RF Family of the product includes cellular, navigation, wifi. While it has a frequency of 850mhz, 900mhz, 1.575ghz, 1.602ghz, 1.8ghz, 1.9ghz, 2.1ghz, 2.4ghz, 4.85ghz, 5.2ghz, 5.65ghz at center/band. The product features sma male (3) termination style. It has a long 11 weeks standard lead time. It is IP rated with ip67. The splendid features of the product include cable - 3m, lna, filter. The product is available in panel mount configuration. It is a dome antenna. The product spartan, is a highly preferred choice for users. VSWR Information: 2, 1.6. Moreover, it corresponds to ma600, a base product number of the product. The product is designated with the 7a994 code number.
