Coil Voltage:
12V dc
Application:
Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine
Terminal Type:
PCB Pin
Coil Resistance:
720Ω
Life:
Minimum of 10000000 (Mechanical) operations
Standards Met:
CQC, CSA, cUL, cULus, UL, VDE
Coil Power:
200mW
Maximum Switching Voltage DC:
30V dc
Maximum Switching Power DC:
150 W
Isolation Coil To Contact:
4kVrms
Maximum Operating Temperature:
+85°C
Switching Current:
10A
Latching:
No
Contact Configuration:
SPST
Depth:
10mm
Mounting Type:
PCB Mount
Length:
20mm
Height:
15.6mm
Maximum Switching Voltage AC:
250V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
1.25 kVA
Number of Poles:
1
Contact Material:
Silver Alloy
This is SPNO Non-Latching Relay PCB Mount 12V dc Coil 10 A Non-Latching Relay manufactured by Panasonic. The manufacturer part number is ALQ312. The coil voltage of the product is 12v dc. Applications Information involves air conditioners, cooking ovens, home appliances, industrial equipment, motor controls, power supply, refrigerators, robots, washing machine. The terminal is a pcb pin type. It holds up to 720ω coil resistance. It is capable of doing minimum of 10000000 (mechanical) operations in a lifetime . The product complies with all safety standards, such as cqc, csa, cul, culus, ul, vde. Robust coil power of 200mw. While it carries 30v dc of maximum DC switching voltage. It bears a maximum 150 w of DC switching power. The product has 4kvrms isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 10a switching current. Latching Options - no. The contact is equipped with spst configuration. The product comes in 10mm depth. The product is available in pcb mount configuration. Its accurate length is 20mm. In addition, the height is 15.6mm. It has a maximum AC switching voltage of 250v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 1.25 kva. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.
