SPDT PCB Mount Non-Latching Relay 10 A, 12V dc

Enrgtech Part No: ET16750223
|
Manufacturer Part No:
ALQ1F12
|
Manufacturer: Panasonic

ALQ1F12 SPDT PCB Mount Non-Latching Relay 10 A, 12V dc

Product Information

Dimensions:

20 x 10 x 15.6mm

Coil Voltage:

12V dc

Application:

Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine

Terminal Type:

PCB Pin

Coil Resistance:

360Ω

Life:

Minimum of 10000000 (Mechanical) operations

Standards Met:

CQC, CSA, cUL, cULus, UL, VDE

Coil Power:

400mW

Maximum Switching Voltage DC:

30V dc

Maximum Switching Power DC:

150 (NO) W, 30 (NC) W

Isolation Coil To Contact:

4kVrms

Maximum Operating Temperature:

+85°C

Checking for live stock

This is SPDT PCB Mount Non-Latching Relay 10 A 12V dc manufactured by Panasonic. The manufacturer part number is ALQ1F12. The given dimensions of the product include 20 x 10 x 15.6mm. The coil voltage of the product is 12v dc. Applications Information involves air conditioners, cooking ovens, home appliances, industrial equipment, motor controls, power supply, refrigerators, robots, washing machine. The terminal is a pcb pin type. It holds up to 360ω coil resistance. It is capable of doing minimum of 10000000 (mechanical) operations in a lifetime . The product complies with all safety standards, such as cqc, csa, cul, culus, ul, vde. Robust coil power of 400mw. While it carries 30v dc of maximum DC switching voltage. It bears a maximum 150 (no) w, 30 (nc) w of DC switching power. The product has 4kvrms isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 10a switching current. Latching Options - no. The contact is equipped with spdt configuration. The product comes in 10mm depth. The product is available in pcb mount configuration. Its accurate length is 20mm. In addition, the height is 15.6mm. It has a maximum AC switching voltage of 250v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 1250 (no) va, 500 (nc) va. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.
