Impulse Discharge Current:
20kA
IP Rating:
IP20
Series:
VAL
Voltage Protection Rating:
4000V
Length:
96.8mm
Width:
35.6 mm
Depth:
65.7mm
Standards/Approvals:
EN 60664-1 / EN 61643-11, IEC 61643-11 Note 2011, EN 61643-11 Note 2012
Minimum Operating Temperature:
-40°C
Electrical Phase:
3
Maximum Surge Current:
30kA
Product Type:
Surge Protector
Maximum Operating Temperature:
80°C
Mount Type:
DIN Rail
HTSUS:
8536.30.8000
RoHS Status:
ROHS3 Compliant
Voltage - Continuous Operating (Max) (MCOV):
750VAC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
cUL, UL
Type:
Type 1
Form:
Base + Module
Voltage - Protection Level (VP) (2416):
2.9 kV
REACH Status:
REACH Unaffected
Current - Discharge (Nom) (8/20µS):
15 kA
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
Not Applicable
standardLeadTime:
6 Weeks
Current - Short Circuit Rating (SCCR):
25 kA
Features:
-
Mounting Type:
DIN Rail
Series:
VAL-US
Voltage - Protection Rating (VPR):
4 kV
Packaging:
Bulk
Current - Discharge (Max) (8/20µS):
30 kA
Number of Poles:
1
ECCN:
EAR99
