Impulse Discharge Current:
2kA
IP Rating:
IP20
Series:
PT
Length:
91.1mm
Width:
17.7 mm
Depth:
77.5mm
Standards/Approvals:
EN 60079-15 Note 2010, EN 60079-11 Note 2012, EN 61000-6-2 Note 2005, IEC 60079-15 Note 2010, IEC 61643-21 Note A2:2012, EN 61000-6-3 Note A1:2011, IEC 60079-11, EN 61643-21 Note A2:2013, EN 60079-0 Note 2018, IEC 60079-0 Note 2017
Minimum Operating Temperature:
-40°C
Voltage Protection Rating:
30V
Maximum Surge Current:
350mA
Product Type:
Surge Protector
Maximum Operating Temperature:
70°C
Mount Type:
DIN Rail
HTSUS:
8536.30.8000
RoHS Status:
RoHS Compliant
Voltage - Continuous Operating (Max) (MCOV):
21VAC, 30VDC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
ATEX, CCC, cUL, cULus, EAC, UL
Type:
-
Form:
Base + Module
Voltage - Protection Level (VP) (2416):
1.5 kV
Current - Discharge (Nom) (8/20µS):
10 kA
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
13 Weeks
Features:
-
Mounting Type:
DIN Rail
Series:
PT
Packaging:
Bulk
ECCN:
EAR99
Number of Poles:
1
Current - Discharge (Max) (8/20µS):
20 kA
