Nippon Chemi-Con 820μF Through Hole Polymer Capacitor, 6.3V dc
Product Information
Diameter:
6.3mm
Ripple Current:
4700mArms
Polarised:
Polar
Dimensions:
6.3 (Dia) x 8mm
Mounting Type:
Through Hole
Series:
PSF
Minimum Operating Temperature:
-55°C
Dissipation Factor:
10%
Height:
8mm
Capacitance:
820µF
Maximum Operating Temperature:
+105°C
Voltage:
6.3V dc
Leakage Current:
1.03 mA
Electrolyte Type:
Solid
Lifetime:
1000h
Lead Pitch:
2.5mm
Dielectric Material Family:
Aluminium
Tolerance:
±20%
Equivalent Series Resistance:
8mΩ
Technology:
Polymer
Ratings:
-
HTSUS:
8532.22.0020
RoHS Status:
ROHS3 Compliant
ESR (Equivalent Series Resistance):
8mOhm
Capacitance:
820 µF
Operating Temperature:
-55°C ~ 105°C
Package / Case:
Radial, Can
Tolerance:
±20%
Voltage - Rated:
6.3 V
Height - Seated (Max):
0.354" (9.00mm)
Type:
Polymer
REACH Status:
REACH Unaffected
Ripple Current @ Low Frequency:
470 mA @ 120 Hz
Applications:
General Purpose
Surface Mount Land Size:
-
Ripple Current @ High Frequency:
4.7 A @ 100 kHz
Package:
Bulk
Size / Dimension:
0.248" Dia (6.30mm)
standardLeadTime:
21 Weeks
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
-
Mounting Type:
Through Hole
Series:
NPCAP™-PSF
Lifetime @ Temp.:
20000 Hrs @ 105°C
Lead Spacing:
0.098" (2.50mm)
Base Product Number:
APSF6R3E
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search APSF6R3ELL821MF08S on website for other similar products.
We accept all major payment methods for all products including ET24730979. Please check your shopping cart at the time of order.
You can order CHEMI-CON brand products with APSF6R3ELL821MF08S directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Polymer Capacitors category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Nippon Chemi-Con 820μF Through Hole Polymer Capacitor, 6.3V dc. You can also check on our website or by contacting our customer support team for further order details on Nippon Chemi-Con 820μF Through Hole Polymer Capacitor, 6.3V dc.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET24730979 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "CHEMI-CON" products on our website by using Enrgtech's Unique Manufacturing Part Number ET24730979.
Yes. We ship APSF6R3ELL821MF08S Internationally to many countries around the world.
This is Nippon Chemi-Con 820μF Through Hole Polymer Capacitor 6.3V dc manufactured by CHEMI-CON. The manufacturer part number is APSF6R3ELL821MF08S. Its diameter is 6.3mm. Furthermore, 4700marms is the ripple current. Furthermore, it is polar polarised. The given dimensions of the product include 6.3 (dia) x 8mm. The product is available in through hole configuration. The product psf, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -55°c. It provides a dissipation factor of 10%. In addition, the height is 8mm. It provides a 820µf of capacitance value. It has a maximum operating temperature of +105°c. It carries a 6.3v dc of voltage. It harbors 1.03 ma of leakage current. It is a solid electrolyte. It provides a long-lasting service for a period of 1000h. The lead features 2.5mm pitch. Whereas its dielectric material family is aluminium. It features ±20% of tolerance value. It has 8mω equivalent series resistance. This product use polymer technology. It is assigned with possible HTSUS value of 8532.22.0020. The product is rohs3 compliant. It carries ESR (Equivalent Series Resistance) of 8mohm. It provides a 820 µf of capacitance value. The product has -55°c ~ 105°c operating temperature range. Moreover, the product comes in radial, can. It also exhibits voltage rating of 6.3 v. It has the maximum seated height of 0.354" (9.00mm). It comes in polymer configuration. In addition, it is reach unaffected. Its ripple current at low frequency is 470 ma @ 120 hz. The product is widely employed in general purpose. Additionally, it carries a ripple current and high frequency of 4.7 a @ 100 khz. It is shipped in bulk package . The product's diameters include 0.248" dia (6.30mm). It has a long 21 weeks standard lead time. Its typical moisture sensitivity level is not applicable. The product npcap™-psf, is a highly preferred choice for users. This product offers longer life span for 20000 hrs @ 105°c. It is assigned with 0.098" (2.50mm) of lead spacing. Moreover, it corresponds to apsf6r3e, a base product number of the product. The product is designated with the ear99 code number.
