Dimensions:
103.7 x 85.6 x 22.5 mm
Temperature Sensing Range:
0 → +200°C
Width:
85.6mm
Frequency Sensing Range:
45 → 65 Hz
Minimum Temperature Sensed:
0°C
Electrical Phase:
3
Maximum Temperature Sensed:
+200°C
Priced to Clear:
Yes
Standards Met:
CAN/CSA 22.2 No.14, CCC, CE, EAC, EMC, EN 50178, GB14048.5 - 2001, GL, IEC/EN 60204, IEC/EN 60255-1, IEC/EN 60947-5-1, RoHS, UL
Maximum Operating Temperature:
+60°C
Terminal Type:
Cage Clamp
Time Delay:
20 ms
Operating Temperature Range:
-40 → +60 °C
Monitoring Application:
Temperature
Contact Configuration:
SPDT
Length:
103.7mm
Maximum Frequency Sensed:
65Hz
Special Features:
All Configurations and Adjustments by Front-Face Operating Elements, Hysteresis 2-20 % Adjustable, One or Two Threshold, 11 LEDs for the Indication of Operational StatesValues
Temperature Sensitivity:
Overtemperature, Temperature Window Monitoring, Undertemperature
Mounting Type:
DIN Rail, Snap-In
Minimum Frequency Sensed:
45Hz
Series:
CM-TCS
Height:
22.5mm
Minimum Operating Temperature:
-40°C
Number of Poles:
1
Supply Voltage:
24 V ac/dc
