NXP 74HC4049D,652, Logic Level Translator, Hex Inverting High to Low Level Shifter, 2 → 6 V, 16-Pin SOIC
Product Information
Maximum Low Level Output Current:
5.2mA
Maximum High Level Output Current:
-5.2mA
Dimensions:
10 x 4 x 1.45mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
130 ns @ 50 pF
Minimum Operating Supply Voltage:
2 V
Logic Function:
Hex Inverting High to Low Level Shifter
Output Type:
Single Ended
Height:
1.45mm
Width:
4mm
Length:
10mm
Package Type:
SOIC
Logic Family:
74HC
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
6 V
Maximum Operating Temperature:
+125 °C
Pin Count:
16
Propagation Delay Test Condition:
50pF
Checking for live stock
FAQs
Yes. You can also search 74HC4049D,652 on website for other similar products.
We accept all major payment methods for all products including ET16753355. Please check your shopping cart at the time of order.
You can order NXP brand products with 74HC4049D,652 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Logic Level Translators category are shipped in lowest possible time.
You will get a confirmation email regarding your order of NXP 74HC4049D,652, Logic Level Translator, Hex Inverting High to Low Level Shifter, 2 → 6 V, 16-Pin SOIC. You can also check on our website or by contacting our customer support team for further order details on NXP 74HC4049D,652, Logic Level Translator, Hex Inverting High to Low Level Shifter, 2 → 6 V, 16-Pin SOIC.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET16753355 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "NXP" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16753355.
Yes. We ship 74HC4049D,652 Internationally to many countries around the world.
This is Logic Level Translator Hex Inverting High to Low Level Shifter 2 → 6 V 16-Pin SOIC manufactured by NXP. The manufacturer part number is 74HC4049D,652. On the other hand, it is featured with 5.2ma of max. low level output current. While a -5.2ma of maximum high level output current. The given dimensions of the product include 10 x 4 x 1.45mm. The product is available in surface mount configuration. It provides up to 130 ns @ 50 pf maximum propagation delay time. While its minimum operating supply voltage is 2 v. The primary function of logic includes hex inverting high to low level shifter. Furthermore, it has asingle ended output. In addition, the height is 1.45mm. Furthermore, the product is 4mm wide. Its accurate length is 10mm. The package is a sort of soic. The logic family is 74hc. Whereas, the minimum operating temperature of the product is -40 °c. It has 6 v maximum operating supply voltage. It has a maximum operating temperature of +125 °c. It contains 16 pins. Features 50pf of propagation delay test condition.
