IP Rating:
IP20
Series:
DM1
Overall Width:
72mm
Maximum Supply Voltage:
240V
Minimum Supply Voltage:
200V
Maximum Operating Temperature:
50°C
Standards/Approvals:
CE, Certified by UL for use in Canada, CSA-C22.2 No. 274-13, CSA-C22.2 No. 274-17, C-Tick, cUL, EAC, IEC/EN 61800-2, IEC/EN 61800-3, IEC/EN61800-3, IEC/EN61800-5, IEC/EN 61800-5-1, ISO 9001, NMMS7, RoHS, UkrSEPRO, UL, UL 508C, UL Category Control No.: NMMS, UL File No.: E134360, UL Listed, UL Report Applies to both US and Canada
Output Frequency:
400Hz
Minimum Operating Temperature:
-10°C
Overall Depth:
180 mm
Power Rating:
0.55kW
Product Type:
Inverter Drive
Maximum Output Current:
3.9A
Number of Phases:
3
Mount Type:
Vertical
