IP Rating:
IP21
Series:
DG1
Drive Type:
Variable Frequency Drive (VFD)
Number of Phases:
3
Maximum Supply Voltage:
500V
Minimum Supply Voltage:
380V
Maximum Operating Temperature:
50°C
Standards/Approvals:
Safety requirements: IEC/EN 61800-5, Specification for general requirements: IEC/EN 61800-2, UL File No.: E134360, cUL, IEC/EN61800-3, C-Tick, UL Category Control No.: NMMS, UL508, Certified by UL for use in Canada, CE, NMMS7, IEC/EN 61800-3, UL Report Applies to both US and Canada, IEC/EN61800-5, UL, UkrSEPRO, ISO 9001, CSA-C22.2 No. 274-13, EAC, RoHS
Output Frequency:
400Hz
Minimum Operating Temperature:
-10°C
Overall Length:
558mm
Overall Depth:
265.1 mm
Power Rating:
22kW
Product Type:
Inverter Drive
Maximum Output Current:
69A
Overall Width:
204.6mm
Mount Type:
Vertical
