IP Rating:
IP54
Series:
DG1
Drive Type:
Variable Frequency Drive (VFD)
Number of Phases:
3
Maximum Supply Voltage:
400V ac
Minimum Supply Voltage:
380V
Maximum Operating Temperature:
50°C
Standards/Approvals:
UL Report Applies to both US and Canada, IEC/EN61800-5, UL508, CSA-C22.2 No. 274-13, Specification for general requirements: IEC/EN 61800-2, UL, IEC/EN 61800-3, UL Category Control No.: NMMS, IEC/EN61800-3, Safety requirements: IEC/EN 61800-5, EAC, ISO 9001, C-Tick, CE Certified by UL for use in Canada, cUL, NMMS7, RoHS, UL File No.: E134360, UkrSEPRO
Output Frequency:
400Hz
Minimum Operating Temperature:
-10°C
Overall Length:
558mm
Overall Depth:
265.1 mm
Power Rating:
18.5kW
Product Type:
Inverter Drive
Maximum Output Current:
38A
Overall Width:
204.6mm
Mount Type:
Vertical
