Contact Finish - Mating:
Gold
Style:
Board to Board or Cable
Contact Finish - Post:
Tin
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 105°C
Contact Finish Thickness - Post:
100.0µin (2.54µm)
Number of Positions:
22
Contact Length - Post:
0.155" (3.94mm)
Insulation Height:
0.410" (10.41mm)
Voltage Rating:
600VAC/DC
REACH Status:
REACH info available upon request
Applications:
General Purpose, Telecommunications
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Insulation Color:
Black
Contact Shape:
Square
Mated Stacking Heights:
-
Package:
Box
Row Spacing - Mating:
0.118" (3.00mm)
Connector Type:
Receptacle
Number of Positions Loaded:
All
Moisture Sensitivity Level (MSL):
Vendor Undefined
Contact Finish Thickness - Mating:
3.00µin (0.076µm)
Fastening Type:
Push-Pull
Termination:
Solder
Current Rating (Amps):
Varies by Wire Gauge
Pitch - Mating:
0.118" (3.00mm)
Ingress Protection:
-
Features:
Blind Mating, Board Guide
Mounting Type:
Through Hole, Right Angle
Series:
Micro-Fit 3.0 BMI 44764
Contact Type:
Female Socket
Contact Material:
Phosphor Bronze Alloy
Insulation Material:
Liquid Crystal Polymer (LCP), Glass Filled
ECCN:
EAR99
Connector System:
Power
Number of Contacts:
22
Orientation:
Right Angle
Series:
44764
Sub Type:
PCB Receptacle
Contact Material:
Phosphor Bronze
Current:
8.5A
Number of Rows:
2
Standards/Approvals:
REACH SVHC
Voltage:
600V
Contact Plating:
Gold
Pitch:
3mm
Termination Type:
Through Hole
Product Type:
Receptacle
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
Mount Type:
Through Hole
