Series:
COMBICON Connectors S
Colour:
Black
Material:
Copper Alloy, Polyamide, Polybutylene Terephthalate
Accessory Type:
PCB Connector
Standards/Approvals:
IEC 60512-3-1:2002-02, IEC 60512-9-1:2010-03, IEC 60512-1-2:2002-02, IEC 60068-2-70:1995-12, IEC 60068-2-6:2007-12, IEC 60512-15-1:2008-05, IEC 60512-5-1:2002-02, IEC 60999-1:1999-11, IEC 60664-1:2007-04, ISO 6988:1985-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02
Product Type:
PCB Connector Accessory
HTSUS:
8536.90.4000
Termination Style:
Screw - Clamping Yoke (Tension Sleeve)
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-40°C ~ 100°C
Screw Size:
-
Wire Strip Length:
10mm
Type:
Plug, Female Sockets
Number of Positions:
8
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.2-1.5mm²
Plug Wire Entry:
180°
Insulation Height:
0.522" (13.25mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Current - IEC:
8A
Wire Gauge or Range - AWG:
16-24 AWG
Voltage - UL:
50 V
Torque - Screw:
-
standardLeadTime:
12 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
Push Button Actuated
Mounting Type:
Free Hanging (In-Line)
Color:
Black
Series:
COMBICON DFMC
Positions Per Level:
4
Header Orientation:
-
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
Number of Levels:
2
ECCN:
EAR99
Contact Material:
Copper Alloy
