HTSUS:
8536.90.4000
Positions Per Level:
3
Termination Style:
Screwless - Leg Spring, Push-In Spring
Housing Material:
Liquid Crystal Polymer (LCP)
Operating Temperature:
-40°C ~ 100°C
Screw Size:
-
Wire Strip Length:
7mm
Type:
Plug, Female Sockets
Number of Positions:
6
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.14-0.5mm²
Plug Wire Entry:
180°
Insulation Height:
0.413" (10.49mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Current - IEC:
6A
Number of Levels:
2
Wire Gauge or Range - AWG:
20-26 AWG
Voltage - UL:
150 V
Torque - Screw:
-
standardLeadTime:
9 Weeks
Contact Mating Finish:
-
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
Push Button Actuated
Mounting Type:
Free Hanging (In-Line)
Color:
Black
Series:
COMBICON DFMC
Header Orientation:
-
Current - UL:
6 A
Pitch:
0.100" (2.54mm)
ECCN:
EAR99
Contact Material:
Copper Alloy
Housing Material:
Liquid Crystal Polymer
Number of Contacts:
3
Series:
DFMC
Colour:
Black
Length:
14.4mm
Current:
6A
Width:
10.12 mm
Depth:
10.5mm
Number of Rows:
2
Standards/Approvals:
IEC 60068-2-82/JEDEC JESD 201, UL 94 V0, IEC 60112, IEC 61984, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, DIN 50018:2013-05, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:2007-04, cULus Recognised (ID: E60425-19920306), VDE report (ID: 40042389), EU RoHS, CHINA RoHS
Voltage:
160 V
Termination Type:
Socket
Pitch:
2.54mm
Product Type:
PCB Terminal Block
Connector Gender:
Female
Mount Type:
Push-in
