HTSUS:
8536.69.4040
Termination Style:
Solder
Housing Material:
Liquid Crystal Polymer (LCP)
Operating Temperature:
-40°C ~ 100°C
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
20
Wire Gauge or Range - mm²:
-
title:
1713369
Plug Wire Entry:
-
Insulation Height:
0.272" (6.91mm)
edacadModel:
1713369 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/17940684
Manufacturer:
Phoenix Contact
Contact Tail Length:
0.079" (2.00mm)
Current - IEC:
8A
Number of Levels:
1
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
8 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Black
Series:
COMBICON MC
Positions Per Level:
20
Packaging:
Bulk
Header Orientation:
90°, Right Angle
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
Contact Material:
Copper Alloy
ECCN:
EAR99
Connector System:
COMBICON MC 1.5
Tail Pin Length:
2mm
Number of Contacts:
20
Termination Type:
Solder
Housing Material:
Liquid Crystal Polymer
Shrouded/Unshrouded:
Shrouded
Series:
MC
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
3.5mm
Current:
8A
Number of Rows:
1
Standards/Approvals:
cULus Recognised, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, ISO 6988, UL 94 V0, VDE
Voltage:
160 V
Contact Plating:
Tin Plated
Pitch:
3.5mm
Mating Pin Length:
2mm
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Mount Type:
Wave Soldering Mount
