Housing Material:
Polyamide
Number of Contacts:
12
Series:
XPC 1
Colour:
Black
Length:
25.95mm
Current:
8A
Width:
43.63 mm
Depth:
12.46mm
Number of Rows:
1
Standards/Approvals:
UL 94, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70:1995-12, UL Recognised Approval ID: E60425-20230810, VDE approval ID: 40057836, IEC 60512-1-2:2002-02, IEC 60999-1:1999-11, cULus Recognised Approval ID: E60425-20230810, IEC 60512-13-5:2006-02, IEC 60664-1:2007-04, IEC 60512-13-2:2006-02, JEDEC JESD 201, EN 60695-10-2, IEC 60112, IEC 60068-2-82, EN ISO 22479:2022-06, IEC 60512-1-1:2002-02
Voltage:
160 V
Termination Type:
Plug-In
Pitch:
3.5mm
Product Type:
PCB Connector
Connector Gender:
Female
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screwless - Push-In Spring
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-40°C ~ 105°C
Screw Size:
-
Wire Strip Length:
10mm
Type:
Plug, Female Sockets
Number of Positions:
12
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.34-1.5mm²
Plug Wire Entry:
180°
Insulation Height:
0.491" (12.46mm)
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
8A
Number of Levels:
1
Wire Gauge or Range - AWG:
16-20 AWG
Torque - Screw:
-
standardLeadTime:
13 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
Lever Actuated
Mounting Type:
Free Hanging (In-Line)
Color:
Black
Series:
COMBICON XPC
Positions Per Level:
12
Packaging:
Bulk
Header Orientation:
-
Pitch:
0.138" (3.50mm)
ECCN:
EAR99
Contact Material:
Copper Alloy
