HTSUS:
8536.69.4040
Termination Style:
Solder
Housing Material:
Polybutylene Terephthalate (PBT)
Operating Temperature:
-40°C ~ 100°C
Screw Size:
-
Wire Strip Length:
-
Type:
Header, Male Pins, Shrouded (4 Side)
Number of Positions:
34
Contact Tail Length:
0.138" (3.50mm)
Wire Gauge or Range - mm²:
-
Plug Wire Entry:
-
Insulation Height:
0.425" (10.80mm)
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Current - IEC:
8A
Wire Gauge or Range - AWG:
-
Voltage - UL:
300 V
Torque - Screw:
-
standardLeadTime:
8 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
160 V
Ingress Protection:
-
Features:
-
Mounting Type:
Through Hole
Color:
Green
Series:
COMBICON DMC
Positions Per Level:
17
Header Orientation:
90°, Right Angle
Current - UL:
8 A
Pitch:
0.138" (3.50mm)
Number of Levels:
2
ECCN:
EAR99
Contact Material:
Copper Alloy
Connector System:
COMBICON
Tail Pin Length:
3.5mm
Number of Contacts:
34
Termination Type:
Solder
Housing Material:
Polybutylene Terephthalate
Shrouded/Unshrouded:
Shrouded
Series:
DMC
Contact Material:
Copper Alloy
Contact Gender:
Male
Row Pitch:
3.5mm
Current:
8A
Number of Rows:
2
Standards/Approvals:
cULus Recognised, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-5-1, IEC 60664-1, ISO 6988, UL 94 V0
Voltage:
160 V
Contact Plating:
Tin Plated
Pitch:
3.5mm
Mating Pin Length:
3.5mm
Product Type:
PCB Header
Maximum Operating Temperature:
100°C
Minimum Operating Temperature:
-40°C
Mount Type:
Wave Soldering Mount
